Housing unit UCF

Name: Housing unit UCF
SKU: UCF210
Availability: InStock

‘- Inner bearing has extended inner ring on both sides with 2 adjusting screws
– Regreasable
– Self-aligning ball bearing
– Wide inner ring ball bearing – Inner bearing has extended inner ring with 2 adjusting screws on both sides
– Can be subsequently lubricated

Part number: UCF210 Categories: Bearings, Hydraulics & Transmission

0 out of 5

(No reviews yet.)Leave a review

€56.22 Incl. VAT€45.71 Excl. VAT

Product Description

Weight	2605 g
Dimensions	161 × 156 × 58 mm
Bearing balls distance to locking side end (mm) \| Bearing Units	22.0 mm
Bearing inner ring width (mm) \| Bearing Units	51.60 mm
Brand \| Global	INA/FAG
Bearing inside diameter (mm) \| Bearing Units	50.000 mm
Grease nipple thread diameter (metric) \| Bearing Units	M6
Housing height (mm) \| Bearing Units/Bearings/Bushings Housings	40.0 mm
Housing type \| Bearing Units/Bearings/Bushings Housings	Square flange
Housing width (mm) \| Bearing Units/Bearings/Bushings Housings	143.00 mm
Mounting holes diameter (mm) \| Bearing Units	16.000 mm
Mounting holes distance (mm) \| Bearing Units/Bearings/Bushings Housings	111.0 mm
Original number equivalent \| Global	UCF210-J7
Total height (mm) \| Bearing Units	54.60 mm
Total length (mm) \| Bearing Units	143.00 mm
